SS304 1.5 INCH Full Bore PTFE Seat Polished Manual Tri Clamp Ball Valve For Beverages

SS304 1.5 INCH Full Bore PTFE Seat Polished Manual Tri Clamp Ball Valve For Beverages Applications: It applied in food, beverage, wine, pharmaceutical and chemical industries. Design Features All-
Pressure:
Low Pressure
Power:
Manual
Size:
1.5"
Connection Form:
Clamp
Material:
Stainless Steel
Certification:
ISO9001:2008
Structure:
Ball
Type:
Manual,Pneumatic,Electric
Media:
Water,Oil,Gas,Chemical liquid

SS304 1.5 INCH Full Bore PTFE Seat Polished Manual Tri Clamp Ball Valve For Beverages

Applications:

It applied in food, beverage, wine, pharmaceutical and chemical industries.

Design Features

All-inclusive tee design, no stranded high clean, meet the requirement of CIP and SIP sterillization and cleaning, and heat resistance of 180°C, the highest pressure 10 bar.

Available with a variety of structures, such as electric pneumatic, stainless steel, horizontal vertical  pneumatic, key manually handle, can also be equipped with the control unit, locata, position sensor and other conpatible automatic control system.

Valve body can be replaced in any connections, adnd the length will not change.

Connection: clamp, weld, thread, flange.

Material for the part contacted with media is 304/636L, other part is 304.

Sealing material: PTFE, it is according to FDA117.2600.

Size: 1/2"-4" / DN10-100   Standard: 3A,DIN, SMS, IDF, RJT, BPE, ISO
